| pole contact composition | 1 NO + 3 NC |
|---|---|
| Contacts operation | Instantaneous |
| [Ue] rated operational voltage | <= 690 V AC <= 400 Hz |
| [Ui] rated insulation voltage | 690 V - for control circuit conforming to BS 5424 690 V - for control circuit conforming to IEC 60947 750 V - for control circuit conforming to VDE 0010 group C 600 V - for control circuit conforming to CSA C22.2 |
| [Ith] conventional free air thermal current | 10 A (at 50 °C) |
| standards | BS 5424 VDE 0660 IEC 60947 NF C 63-110 |
| product certifications | CSA UL |
| Irms rated making capacity | 110 A at <= 690 V AC conforming to IEC 60947 |
|---|---|
| permissible short-time rating | 80 A 1 s 60 A 500 ms 110 A 100 ms |
| associated fuse rating | 10 A gG at <= 690 V conforming to IEC 60947 10 A gG at <= 690 V conforming to VDE 0660 |
| minimum switching current | 5 mA |
| minimum switching voltage | 17 V |
