| range of product | Fusarc CF |
|---|---|
| quality labels | ISO 14001 ISO 9001 |
| standards | IEC 60282-1 IEC 60787 DIN 43625 VDE 0670-402 |
| product or component type | Fuse |
| protection technology | Current limiter Thermal limiter |
| [In] rated current | 63 A |
|---|---|
| Rated voltage (Ur) | 24 kV |
| [Ue] rated operational voltage | 10...24 kV |
| maximum discharge current | 31.5 kA |
| braking current | 265 A |
| average resistance | 25.2 mOhm at 20 °C +/- 10 % |
| power dissipation in W | 144 W |
| type of installation | Indoor/outdoor |
| material | Porcelain |
| product destination | Motor Power transformer Capacitor Voltage transformer |
| condition of use | Cubicle In open air Fuse chamber |
| length | 442 mm |
| net weight | 4.5 kg |
